Description
120 V, 50/60 Hz transformer on a 4 x 4 mounting plate, with 9 in primary and secondary leads that extend through the plate.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: AT72D1956/U
- Application: 40 VA transformers power 24 V systems including thermostats, gas valves and relays.
- NEMA Rating: Yes
- Primary Connection Size: 9 in, 229 mm
- Primary Connection Type: Leadwires: Black and White
- Primary Input Voltage: 208/240 V ac
- Secondary Connection Type: (2) screw terminals
- Secondary Open Circuit Voltage: 26.5 V.O.C.
- VA Rating: 40 VA
- Frequency: 50 Hz; 60 Hz
- Approvals and Standards: UL Component Recognized, CSA Certified, NEC Class 2
- Ambient Operating Temperature (Max): 105 °F, 41 °C
- Ambient Operating Temperature (Min): -20 °F, -29 °C
- Product Height: 6.44 in, 164 mm
- Product Width: 3 in, 76 mm
- UPC: 085267161145
- Country of Origin: CN
- Category: Transformers
