Description
120 VAC, 60 Hz control with 30-second safety switch timing, 0.2 A thermostat current rating, LED lockout indication, and manual trip.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: R8184G4033/U
- Application: Controls oil burner, oil valve and the ignition transformer in response to a call for heat
- Approvals and Standards: UL Component Recognized; File no. MP268, Vol. 35 Sec. 3, CSA Certified; File no. LR95329-1
- Ignition Type: Intermittent
- Electrical Ratings at Full Load: 7.4 A @ 120 Vac; 3.7 a @ 240 Vac
- Electrical Ratings at Locked Rotor: 44.4 A @ 120 Vac; 22.2 A @ 240 Vac
- Color: Gray
- Product Height: 4.38 in, 111 mm
- Product Width: 4.13 in, 120 mm
- UPC: 085267078658
- Country of Origin: US
- Category: Oil Burner Controls
