Description
Electric heat relay with built-in transformer, 600/24 V.
Features
- Operate with each cycle of the thermostat (4 to 6 cycles per hour)
- Each relay switches up to a 5,000 W load
- Contacts make and break in about 75 seconds
- Mount in any position
- Includes 1/2 in. (13 mm) male conduit bushing
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: R841C1151/U
- Application: SPST switching Electric Heater Relay
- Approvals and Standards: UL Component Recognized: File No.E47434, Guide No. XAPX, CSA Certified
- Includes: Integral transformer, Enclosure with Conduit brushing
- Coil Rating Voltage: 600 V AC
- Number of Poles: 1 Pole
- Operating Frequency: 50 Hz, 60 Hz
- Power Supply Frequency: 50 Hz, 60 Hz
- Switch Action: SPST
- Warranty: 1 Year
- Ambient Operating Temperature (Min): -20 °F, -29°C
- Ambient Operating Temperature (Max): 150 °F, 66 °C
- Product Height: 3.87 in, 98 mm
- Product Length: 1.5 in, 38 mm
- Product Width: 2.81 in, 71 mm
- UPC: 085267128667
- Country of Origin: MX
- Category: Relays
