Description
Electromechanical electric heat relay with built-in transformer, 277/24 V.
Features
- Compatible with 24 V thermostats with 2-wire connections (R
- W) or 3-wire connections (R
- W
- C)
- Epoxy-soundproofed relay ensures quiet operation
- Low current consumption means multiple relays can be controllers by a single thermosta
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: RC840T-277/U
- Application: Control a line voltage resistive load from a low voltage thermostat
- Approvals and Standards: UL Approved
- Compatible With: 2 and 3 wire thermostats
- For Use With: TH140-28-01-B; TH135-01-B; TH114-A-024T; TH115-A-024T
- Includes: Lock-nut
- Operating Frequency: 60 Hz
- Switch Action: On/Off Switching
- Compatible Thermostat: Compatible with 24 V thermostats with 2-wire connections (R, W) or 3-wire connections (R, W, C)
- Warranty: 3 Years
- Ambient Operating Temperature (Min): -4 °F, -20 °C
- Ambient Operating Temperature (Max): 140 °F, 60 °C
- Shipping and Storage Temperature (Min): -40 °F, -40 °C
- Shipping and Storage Temperature (Max): 175 °F, 80 °C
- Product Height: 3.22 in, 82 mm
- Product Width: 2.28 in, 58 mm
- UPC: 775264094637
- Country of Origin: CN
- Category: Relays
