Description
Low voltage non-programmable thermostat rated 0.5 A at 24 V with R, C, W terminals, 15-minute cycles, and a backlit screen.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: TH114-A-024T/U
- Application: Electric Heating; Baseboard heater; Radiant ceiling; Convector or Fan-forced Heater
- Thermostat Type: Low Voltage, Non programmable
- Smart Home Integration: No
- Display Type: LCD Screen
- Display Size: 6.89 sq in
- Modes of Operation: Heat
- Program Type: Manual / Not Programmed
- Energy Star Certified: No
- Power Supply: Hardwired
- Warranty: 3 Years
- For Use With: Aube RC840/RC840T Series Electromechanical Relays
- Z-Wave Specifications: Not Applicable
- RedLINK: No
- Color: White
- Sensor Type: Thermistor
- Ambient Operating Temperature (Max): 122 °F, 50 °C
- Ambient Operating Temperature (Min): 32 °F, 0 °C
- Differential Temperature: ± 1 °F, ± 0.5 °C
- Backlight Options: Backlight Button
- Temperature Accuracy: 0.9, 0.5
- Electrical Connection Type: UWP Mounting System
- Mounting Type: Vertical Mount
- Number of Fan Speeds: 2
- Set point Temperature (Max): 86 °F, 30 °C
- Set point Temperature (Min): 40 °F, 5 °C
- Switch Type: External electromechanical relay
- Product Height: 4.9 in, 2.8 mm
- Product Length: 2.8 in, 70 mm
- Product Width: 0.9 in, 23 mm
- UPC: 775264924545
- Country of Origin: CN
- Category: Non-Programmable Thermostats
