Mueller Streamline 511-603 1/2" - Galvanized Floor Flange

Mueller Streamline 511-603 is a 1/2" floor flange in galvanized malleable iron, FPT (FPT = female pipe thread).

A floor flange screws down to a floor, wall or ceiling and takes a threaded pipe, for pipe supports, railings or equipment stands.

These are Class 150 malleable iron fittings with a hot-dip zinc coating to ASTM A153, which protects the iron where it is exposed to moisture: compressed air, non-potable water, vents and outdoor runs. Threads are tapered NPT and make up with galvanized pipe and nipples. Check the local code before using galvanized on potable water or fuel gas.

Specifications

• Brand: Mueller Streamline
• Manufacturer Part #: 511-603
• Size: 1/2"
• Type: Floor Flange
• Connections: FPT
• Material: Malleable iron, Class 150, hot-dip galvanized
• Standards: ASME B16.3 dimensions, ASME B1.20.1 NPT threads, zinc coating to ASTM A153
• Pressure rating: 300 psi (Class 150)
• UPC: 032888369610
• Shipping Weight: 1.36 lb
• Category: Galvanized Iron Fittings

See also: all galvanized iron fittings, thread sealant, galvanized nipples, all Mueller Streamline.
