Viega 49414 3/4" x 1" PEX PureFlow Press Manifold Tee Supply Adapter (Press x FIP) - Composite

Viega 49414 is a 3/4" x 1" PureFlow Press PEX manifold tee supply adapter in PPSU polymer (Press x FIP).

A manifold tee feeds several PEX branch lines from one supply, keeping the take-offs in one place.

Viega PureFlow Press makes a PEX joint with a factory-attached stainless steel sleeve. The three view holes show the tubing is fully inserted, and the press is made with a PureFlow hand tool or power tool. PureFlow Press is approved for hot and cold potable water and, with Viega Barrier PEX, for hydronic heating and cooling.

Specifications

• Brand: Viega
• Manufacturer Part #: 49414
• System: PureFlow Press
• Size: 3/4" x 1"
• Type: Manifold Tee Supply Adapter
• Connections: Press x FIP
• Material: PPSU polymer
• Press sleeve: 304 stainless steel, factory attached, with view holes
• Rating: 160 psi at 73°F, 100 psi at 180°F
• Temperature: 180°F max potable, 200°F max hydronic
• Listings: ASTM F3347 / F3348, CSA B137.5, NSF-pw 372
• UPC: 691514494142
• Shipping Weight: 0.5 lb
• Dimensions: 1.591 x 1.417 x 1.417 in (L x W x H)
• Category: Viega PureFlow Press Fittings
