Caleffi ZVR104 Z-One 4-Zone Expandable Zone Valve Control with Priority, 120VAC Input, 24V 40VA

Roll over image to zoom in Click on image to zoom

Caleffi ZVR104 Z-One 4-Zone Expandable Zone Valve Control with Priority, 120VAC Input, 24V 40VA

Name: Caleffi ZVR104 Z-One 4-Zone Expandable Zone Valve Control with Priority, 120VAC Input, 24V 40VA
Brand: Caleffi
SKU: CALE-ZVR104
Price: 216.99 USD
Availability: InStock

CaleffiSKU: CALE-ZVR104

Price:

$216.99

Stock:

Re-stocking soon

Quantity:

Special order — typically ships in 1–3 weeks.
Contact us for an exact lead time.

Questions? Call (404) 678-9908 or chat with us.

Need 10+ or a project quote? Request a quote · Pros: open a trade account

Free shipping on orders $99+ · 30-day returns · Manufacturer warranty

Shipping details

Shipping weight: 4.9 lb
Box size: 12.75 × 12.3 × 3.4 in

Type	Zone Valve Controls

The Caleffi ZVR104 Z-One is a 4-zone switching relay for zone valves, with 120VAC input, a 24V 40VA output, and priority.

It powers 24V zone valves from the thermostat calls and signals the boiler and system circulator when a zone opens. The priority function lets one zone, typically indirect domestic hot water, take precedence. The control is expandable for additional zones, and the enclosure measures 9.25" high x 11" wide x 3" deep.

Before ordering, confirm your zone valves are 24V and that the total actuator load fits within the 40VA rating. See the installation manual for wiring with and without end switches.
