| Connection Type | FIP x FIP |
| Material | Lead Free Brass |
| WOG | 600 |
Description
Jomar 100-405G is a 1" FIP x FIP two-piece full port ball valve in dezincification resistant, lead free brass, rated 600 WOG.
Full port means the ball bore is sized to match the pipe, which keeps flow restriction low. The 600 WOG rating refers to the water, oil and gas pressure rating of the valve, and the body is dezincification resistant brass.
Both ends are female threaded (FIP x FIP), so the pipe or nipple on each side needs a male thread. Apply thread sealant suited to the service, avoid over-tightening the body and check handle clearance before mounting. Confirm that the 1" size and pressure rating suit the application; the specification sheet is linked below.
Specifications
- Brand: Jomar
- Manufacturer Part #: 100-405G
- Connection Type: FIP x FIP
- Material: Lead Free Brass
- WOG: 600
- Size: 1"
- Body: 2 Piece, Full Port
- UPC: 662527290526
- Category: FIP Ball Valves
Documents
- Specification Sheet (PDF)
