Jomar 105-204G is a 3/4" solder horizontal swing check valve rated 200 WOG.
A swing check valve lets water flow in one direction and closes with a hinged disc to stop backflow; install it in horizontal lines with the flow arrow pointing downstream.
This model has a solder connection. Check the pipe size, connection type and system pressure before ordering.
Specifications
-
Brand: Jomar
-
Manufacturer Part #: 105-204G
-
Size: 3/4"
-
Type: Horizontal Swing Check Valve
-
Connection: Solder
-
Pressure Class: Class 125
-
Pressure Rating: 200 WOG
-
UPC: 662527294708
-
Category: Check Valves
