Tyler Pipe 011217 is a 3" x 3" P-trap with 1/2" primer tap for cast iron drain, waste and vent (DWV) systems.
This P-trap with 1/2" primer tap provides the water seal at a floor drain, and the 1/2" primer tap lets a trap primer keep the seal from evaporating. It is designed for no-hub (NH) connections, which are joined with no-hub couplings rather than lead and oakum or hub gaskets. When choosing it, confirm the size (3" x 3") against your pipe, check the fitting pattern your layout needs, and select couplings of the matching size and duty rating.
Specifications
-
Brand: Tyler Pipe Company
-
Manufacturer Part #: 011217
-
Description: 3" x 3", NH x NH, Cast Iron DWV, Straight, P-Trap with 1/2" Primer Tap
-
Material: Cast iron
-
Connection: No-hub
-
Category: No Hub Fittings
-
Shipping Weight: 8.9 lb
See also: No Hub Fittings, Tyler Pipe Company, P-Traps, Shielded Couplings.
