Resideo AM100-002RP/U Rebuild Kit for AM Standard Series Mixing Valves
- Item #
- HONE-AM100-002RP/U
- Mfr. part #
- AM100-002RP/U
- UPC
- 085267824675
| Brand | Resideo |
| Manufacturer part # | AM100-002RP/U |
| Valve Type | Mixing Valves |
| Operating Temperature | 110 F to 145 F; 80 F to 180 F |
| Application | old style' AM series valve |
| Includes | Element, sprint, and plug assembly |
| UPC | 085267824675 |
Rebuild kit for AM Standard Series Mixing Valves from Resideo (Honeywell Home), part number AM100-002RP/U.
A mixing valve that has drifted off setpoint or that weeps at the union is usually rebuilt rather than replaced. The cartridge, the gaskets and the tailpieces are the parts that wear; the body outlasts them by years.
Match the kit to the valve series and size. The AM and AM-1 families share a name across sizes that do not share internals.
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: AM100-002RP/U
- Type: Mixing valve service part
- UPC: 085267824675
- Shipping weight: 0.2 lb
- Category: Mixing Valve Parts
- Product Data for AM100C1070, AM101C1070, AM102C1070, AM-1 Series Proportional Thermostatic Mixing Valve (English) (0.6MB PDF)
- Installation instruction for AM-1 Series Mixing Valve Temperature Guage Adapter (English, French, Spanish) (1.1MB PDF)
- Installation Instructions for AM-1 Series Proportional Thermostatic Mixing and Diverting Valve (English, French, Spanish) (1.1MB PDF)
- Sell Sheet for AM-1 Series Thermostatic Mixing Valve (English) (1.1MB PDF)
- Sell sheet for AM-1 1070 Series Thermostatic Mixing Valve (English) (1.3MB PDF)
- Brochure for Homeowners for AMX 300 Thermostatic Mixing Valves (English) (1.8MB PDF)
- Brochure for the Hydronic Products with Press Fittings (English) (9.4MB PDF)
- Make Your Own Mixing Valve (English) (0.4MB PDF)
Questions about fit or compatibility? Ask our team. We usually reply within one business day.
$53.96
In stock
