0.316" x 19.27", 1" NPSM, 208 to 240 V, 4500/6000 W, Threaded Mount, Stainless Steel, Resistored/Screw-In, Water Heater Heating Element
Rheem

Rheem 0.316" x 19.27", 1" NPSM, 208 to 240 V, 4500/6000 W, Threaded Mount, Stainless Steel, Resistored/Screw-In, Water Heater Heating Element

Item #
RHEE-SP10869QL
Mfr. part #
SP10869QL
UPC
020352193373

$53.64
Each
In stock
Estimated delivery: –

Usually ships in 1–2 business days.

Replaces: AP10869QL-5

  • Free shipping on orders $99+
  • 30-day returns on unused items. Details
  • Secure checkout

Shipping details

  • Shipping weight: 1.2 lb
  • Box size: 23.4 × 3.55 × 1.75 in
Need help with this part?
(404) 678-9908 Chat with a product specialist Request a quote
BrandRheem
Manufacturer part #SP10869QL
TypeHeating Element
UPC020352193373

Rheem SP10869QL is the Rheem Manufacturing 0.316" x 19.27", 1" NPSM, 208 to 240 V, 4500/6000 W, Threaded Mount, Stainless Steel, Resistored/Screw-In, Water Heater Heating Element.

It is a screw-in replacement heating element for Rheem electric and hybrid tank water heaters. Elements fail from scale buildup, dry firing or age, and a matching replacement restores recovery without changing the tank. Rheem parts are matched to specific heater models, so check the model and serial number on the rating plate to confirm the fit.

Match the voltage, wattage and length to the rating plate and the element being removed. Turn off power, drain the tank below the element opening, and refill completely before restoring power to avoid a dry-fire failure.

Specifications

  • Brand: Rheem Manufacturing
  • Manufacturer Part #: SP10869QL
  • Voltage: 208 to 240 V
  • Wattage: 4500/6000 W
  • Size: 0.316" x 19.27"
  • Connection: 1" NPSM
  • Material: Stainless Steel
  • UPC: 020352193373
  • Category: Elements & Electric Conversion Kits

See also: Rheem Manufacturing, Electric Elements & Conversion Kits, Water Heating.

Questions about fit or compatibility? Ask our team. We usually reply within one business day.

$53.64
In stock
