Mueller Streamline PF 02581 3/4" Copper Press Fittings - Drop Ear 90 Degree Elbow P x FPT

Mueller Streamline PF 02581 is a 3/4" drop ear 90 degree elbow for copper tube, P x FPT (P = press socket, FPT = female pipe thread).

A drop-ear elbow has a mounting tab that screws to the framing, which is how a shower arm or hose bibb connection is held solid in the wall.

Streamline PRS copper press fittings make a permanent joint with a press tool and the matching copper jaw, with no flame and no solder. They are listed to ASME B16.51 and certified to NSF/ANSI 61 and 372 for drinking water, and are used on potable water, hydronic heating with glycol, chilled water and compressed air. The tube has to be cut square, deburred and fully inserted to the depth mark before pressing.

Specifications

• Brand: Mueller Streamline
• Manufacturer Part #: PF 02581
• Size: 3/4"
• Type: Drop Ear 90 Degree Elbow
• Connections: P x FPT
• Material: Copper, EPDM sealing element
• Standards: ASME B16.51, IAPMO PS-117, NSF/ANSI 61 and 372
• Temperature: -20°F to 250°F
• Tube: ASTM B88 Type K, L or M copper
• UPC: 685768395003
• Shipping Weight: 0.29 lb
• Category: Press Fittings - Copper (CTS)
