MrPEX Systems 3052061 6-Port PEX Flow Through Manifold Tee - 1" Expansion Inlet, 3/4"Expansion Outlet - (6) 1/2" Expansion Ports - Composite

MrPEX Systems 3052061 is a 6-port composite PEX manifold tee with a 1" expansion inlet and (6) 1/2" expansion branch ports.

Manifold tees let you split a supply line into several PEX branches in a compact space, for example to feed fixtures in a bathroom group or a kitchen. This model uses a flow-through design with an outlet, so several tees can be linked in series. Outlet connection: 3/4" expansion.

Before ordering, confirm the connection system: this tee is made for F1960 expansion connections, so use the matching rings or sleeves and tooling. Also check the inlet size against your trunk line and the port count against the number of fixtures you need to serve.

Specifications

• Brand: MrPEX Systems
• Manufacturer Part #: 3052061
• Type: Flow-through PEX manifold tee
• Ports: (6) 1/2"
• Inlet: 1" Expansion
• Outlet: 3/4" Expansion
• Connection: ASTM F1960 expansion
• Material: Composite
• UPC: 603981263893
