Caleffi 535370HA PressCal Pressure Reducing Valve, 1-1/4" Female NPT, ASSE 1003, Low Lead

Roll over image to zoom in Click on image to zoom

Caleffi 535370HA PressCal Pressure Reducing Valve, 1-1/4" Female NPT, ASSE 1003, Low Lead

Name: Caleffi 535370HA PressCal Pressure Reducing Valve, 1-1/4" Female NPT, ASSE 1003, Low Lead
Brand: Caleffi
SKU: CALE-535370HA
Price: 377.99 USD
Availability: InStock

CaleffiSKU: CALE-535370HA

Price:

$377.99

Stock:

Re-stocking soon

Quantity:

Special order — typically ships in 1–3 weeks.
Contact us for an exact lead time.

Questions? Call (404) 678-9908 or chat with us.

Need 10+ or a project quote? Request a quote · Pros: open a trade account

Free shipping on orders $99+ · 30-day returns · Manufacturer warranty

Shipping details

Shipping weight: 5.8 lb
Box size: 11 × 9.25 × 4 in

Connection Type	FIP
Size	1-1/4"
Type	PRV's

The Caleffi 535370HA is a PressCal pressure reducing valve (PRV) with 1-1/4" female NPT threaded connections, supplied without a gauge. It reduces high incoming water pressure to a steady, adjustable outlet pressure.

PressCal valves are ASSE 1003 listed, low-lead, pre-adjustable PRVs for domestic water systems, typically installed on the main water service after the meter to protect fixtures, appliances and piping from excess pressure. The brass body is rated for a maximum pressure of 300 psi.

Before ordering: match the PRV to your 1-1/4" service line and confirm the female NPT connection. Male threaded nipples or adapters are needed on both sides. If you want to read outlet pressure at the valve, choose a version with a gauge. Check local code for thermal expansion requirements once a PRV is installed.
