| Frequency | 50 Hz; 60 Hz |
| Electrical Connections | lug connectors |
| Application | PowerPro Definite Purpose Contactor |
| Dimensions | 2.2 in. high x 2.5 in. wide x 3.31 in. deep |
| UL | Component Recognized: File No. 14480, Guide No. NLDX2 |
| CSA | Certified: File No. LR6535 |
| Temperature Ratings (F) | -4 F to +149 F |
| Switching | DPST |
| Contact Ratings (AFL) | 30 A @ 240, 277, 480, 600 Vac |
| Contact Ratings (resistive) | 25 A @ 240/277 Vac, 480 Vac, 600 Vac |
| Poles | 2 |
| Contact Connections (coil) | 1/4 in. quick-connects |
| Coil Ratings Voltage | 24 Vac |
Description
The DP2020A5022 is a definite purpose contactor from Resideo (Honeywell Home), rated 20 amps and built with 1 pole and a 24 Vac coil. It is the switch that lets a low-power control circuit start a compressor, a condenser fan, or an electric heat bank.
A definite purpose contactor is sized for one job rather than for general industrial duty, which is why it costs a fraction of a general purpose starter and still carries the inrush of an air conditioning compressor. The coil pulls the contacts closed when the thermostat or control board calls; when the call drops, spring pressure opens them.
A single-pole contactor switches one leg of the supply and leaves the other connected. It is the common arrangement on residential condensing units, where the manufacturer has already accounted for the unswitched leg in the unit wiring.
The 24 Vac coil is driven straight from the low-voltage control transformer, so the thermostat circuit never carries line current.
Confirm the pole count before ordering. The part number and the product title disagree on this item. Send us the model stamped on the contactor you are replacing and we will confirm the match.
Match poles, coil voltage and amp rating to the contactor you are replacing. A contactor with the right coil but too few poles will run the equipment and leave a leg energized at the unit.
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: DP2020A5022/U
- Poles: 1
- Coil voltage: 24 Vac
- Rating: 20 A
- UPC: 085267133494
- Category: Contactors
