Resideo DP2030D5002/U 277 Vac 2 Pole Deluxe Definite Purpose Contactor

Item #: HONE-DP2030D5002/U
Mfr. part #: DP2030D5002/U
UPC: 085267540865

Key specifications

Frequency50 Hz; 60 Hz
Electrical Connectlug connectors
Temperature Rating-4 F to +149 F
SwitchingDPST
Contact Ratings30 A @ 240/277 Vac

View all specifications

$22.89

Ships from Seattle, WA
30-day returns on unused items. Details
Secure checkout

Shipping details

Shipping weight: 0.55 lb
Box size: 3.38 × 2.5 × 2.25 in

Need help with this part?

(404) 678-9908 Chat with a product specialist Request a quote

Brand	Resideo
Manufacturer part #	DP2030D5002/U
Frequency	50 Hz; 60 Hz
Electrical Connections	lug connectors
Application	PowerPro Definite Purpose Contactor
Dimensions	2.2 in. high x 2.5 in. wide x 3.31 in. deep
UL	Component Recognized: File No. 14480, Guide No. NLDX2
CSA	Certified: File No. LR6535
Temperature Ratings (F)	-4 F to +149 F
Switching	DPST
Contact Ratings (AFL)	30 A @ 240/277 Vac
Contact Ratings (resistive)	40 A @ 240/277 Vac, 480 Vac, 600 Vac
Poles	2
Contact Connections (coil)	1/4 in. quick-connects
Coil Ratings Voltage	277 Vac
UPC	085267540865

DP2030D5002 has been discontinued by the manufacturer (2025-07). Direct replacement: DPL2030D5002 - 277 VAC 2 Pole PowerPro Deluxe Definite Purpose Contactor (30 A).

The DP2030D5002 is a definite purpose contactor from Resideo (Honeywell Home), rated 30 amps and built with 2 poles and a 277 Vac coil. It is the switch that lets a low-power control circuit start a compressor, a condenser fan, or an electric heat bank.

A definite purpose contactor is sized for one job rather than for general industrial duty, which is why it costs a fraction of a general purpose starter and still carries the inrush of an air conditioning compressor. The coil pulls the contacts closed when the thermostat or control board calls; when the call drops, spring pressure opens them.

Two poles break both legs of a 240 V single-phase supply, which fully isolates the load when the contactor drops out. Specify two poles where the equipment or the local code calls for both legs to open.

The 277 Vac coil is driven from line voltage, which suits equipment where no low-voltage control transformer is present.

The Deluxe tier sits between the economy and heavy-service lines, adding contact life over the base model without the full PowerPro price.

Match poles, coil voltage and amp rating to the contactor you are replacing. A contactor with the right coil but too few poles will run the equipment and leave a leg energized at the unit.
