Legend Valve 105-518NL 2" - Sweat x Sweat; Includes 20-Mesh Stainless Steel Screen, No Lead Cast Bronze Y-Strainer

Legend Valve 105-518NL is a 2" y-strainer, Sweat x Sweat.

A Y-strainer traps scale and debris ahead of pumps, valves and meters; the screen is cleaned by removing the cap.

Sweat ends solder onto copper tube; keep the heat off the valve body and seats while soldering.

Specifications

• Brand: Legend Valve
• Manufacturer Part #: 105-518NL
• Size: 2"
• Type: Y-Strainer
• Connections: Sweat x Sweat
• Material: Cast Bronze
• Lead content: No Lead (0.25% max weighted lead, NSF/ANSI 372)
• UPC: 662545083230
• Category: Y-Strainers

Features

• Legend S-15NL Y-strainer, 2" sweat x sweat (solder) connections
• Heavy-duty, full-pattern body resists pipeline stresses and distortion
• Body, cap and closure plug: lead-free cast bronze, ASTM B584 UNS C89836
• 304 stainless steel 20-mesh screen (replacement 20-mesh or optional 40 or 80 mesh screens available)
• Pressure ratings: 300 psi cold working pressure (CWP), 150 psi saturated steam (WSP)
• Square-head closure (blow-off) plug, 1/2" NPT, for flushing out sediment
• Certified to NSF/ANSI 61 (drinking water system components); solder ends per ANSI/ASME B16.18
• Dimensions (sweat x sweat): A = 8.62 in, B = 5.12 in
