1-1/2" - Sweat x Sweat; Includes 20-Mesh Stainless Steel Screen, No Lead Cast Bronze Y-Strainer

Roll over image to zoom in Click on image to zoom

Legend Valve 105-517NL 1-1/2" - Sweat x Sweat; Includes 20-Mesh Stainless Steel Screen, No Lead Cast Bronze Y-Strainer

Name: Legend Valve 105-517NL 1-1/2" - Sweat x Sweat; Includes 20-Mesh Stainless Steel Screen, No Lead Cast Bronze Y-Strainer
Brand: Legend Valve
SKU: LEGE-105-517NL
Price: 172.06 USD
Availability: InStock

Legend ValveSKU: LEGE-105-517NL

Price:

$172.06

Stock:

Only 2 units left

Quantity:

Usually ships in 1–2 business days.

Questions? Call (404) 678-9908 or chat with us.

Need 10+ or a project quote? Request a quote · Pros: open a trade account

Free shipping on orders $99+ · 30-day returns · Manufacturer warranty

Shipping details

Shipping weight: 3.7 lb

⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Connection Type	Sweat x Sweat; Includes 20-Mesh Stainless Steel Screen
Size	1-1/2"
Series	S-15NL
Configuration	Sweat x Sweat; Includes 20-Mesh Stainless Steel Screen
Product Type	No Lead Cast Bronze Y-Strainer

Legend Valve 105-517NL is a 1-1/2" y-strainer, Sweat x Sweat.

A Y-strainer traps scale and debris ahead of pumps, valves and meters; the screen is cleaned by removing the cap.

Sweat ends solder onto copper tube; keep the heat off the valve body and seats while soldering.

Specifications

Brand: Legend Valve
Manufacturer Part #: 105-517NL
Size: 1-1/2"
Type: Y-Strainer
Connections: Sweat x Sweat
Material: Cast Bronze
Lead content: No Lead (0.25% max weighted lead, NSF/ANSI 372)
UPC: 662545083223
Category: Y-Strainers

Features

S-15NL full-pattern Y-strainer, 1-1/2" sweat x sweat (solder) connections per ASME B16.18
Traps and holds pipeline debris to protect downstream valves, pumps and equipment
Body, cap and closure plug in no lead cast bronze (ASTM B584 UNS C89836); heavy-duty body resists pipeline stress and distortion
304 stainless steel 20-mesh screen; replacement 20-mesh and optional 40 or 80-mesh screens available
1/2" NPT square-head closure (blowoff) plug for flushing out sediment
Rated 300 psi cold working pressure (CWP) and 150 psi saturated steam (WSP), non-shock
Nitrile-bonded non-asbestos fiber cap gasket
Certified to NSF/ANSI 61 (drinking water system components)
Approx. 6.89 in end to end and 4.13 in dimension B (centerline to screen cap) per Legend spec sheet
