Grundfos 95906630 UPS26-150F 3-Speed Circulator, Cast Iron, Flanged, 1/2 HP, 115V

The Grundfos 95906630 is a UPS26-150F three-speed wet-rotor circulator with a cast iron pump housing and flanged connections.

UPS circulators are wet-rotor pumps with a manual three-speed selector on the terminal box, so the duty point can be matched to the system. The cast iron housing is intended for closed-loop hydronic heating and cooling systems. This model handles flows up to 53 GPM and a maximum head of 45 ft.

Before ordering: confirm your supply voltage (115V, single phase), and that you have a matching flange set for your pipe size.

Specifications

• Brand: Grundfos
• Manufacturer Part #: 95906630
• Series: UPS
• Model: UPS26-150F
• Type: 3-speed wet-rotor circulator
• Body Material: Cast Iron
• Connection: Flanged x flanged
• Max Flow: 53 GPM
• Max Head: 45 ft
• Max Pressure: 145 psi
• Voltage: 115V, 1 phase, 60 Hz
• Amperage: 3.5 A
• Wattage: 370 W
• Horsepower: 1/2 HP
• UPC: 5700313291670
• Category: Fixed Speed Circulators

Documents

• Installation & Operation Manual (PDF)

See also: fixed speed circulators, all Grundfos products.
