Grundfos 95906637 UPS43-100F 3-Speed Circulator, Cast Iron, Flanged, 230V

The Grundfos 95906637 is a UPS43-100F three-speed wet-rotor circulator with a cast iron pump housing and flanged connections.

UPS circulators are wet-rotor pumps with a manual three-speed selector on the terminal box, so the duty point can be matched to the system. The cast iron housing is intended for closed-loop hydronic heating and cooling systems. This model handles flows up to 60 GPM and a maximum head of 30 ft.

Before ordering: confirm your supply voltage (230V, single phase), and that you have a matching flange set for your pipe size (listed connection sizes: 1-1/2").

Specifications

• Brand: Grundfos
• Manufacturer Part #: 95906637
• Series: UPS
• Model: UPS43-100F
• Type: 3-speed wet-rotor circulator
• Body Material: Cast Iron
• Connection: Flanged x flanged
• Connection Size: 1-1/2"
• Max Flow: 60 GPM
• Max Head: 30 ft
• Max Pressure: 145 psi
• Voltage: 230V, 1 phase, 60 Hz
• UPC: 5700313291755
• Category: Fixed Speed Circulators

Documents

• Installation & Operation Manual (PDF)
