| Application |
Residential, Commercial, Potable Water |
| Connection Size |
1/2" x 1/2" |
| Connection Type |
FNPT x FNPT |
| ASSE Standard |
ASSE 1003 |
| Finish/Color |
Bronze |
| Height |
5.5" |
| Length |
5.5" |
| Material |
Low Lead Cast Bronze |
| Maximum Working Water Pressure |
400 psi |
| Maximum Working Water Temperature |
140 deg F |
| Mounting Type |
Vertical, Horizontal |
| Size |
1/2" |
| Valve Body Material |
Low Lead Cast Bronze |
| Weight |
1.972 lbs |
| Width |
2.8" |
| Pressure Type |
Adjustable Pressure |
| Reduced Pressure Range |
15-75 psi |
| Valve Style |
In-line (Backflow, PRVs, TMVs, RVs, etc.) |
