| Application |
Residential, Commercial, Potable Water |
| ASSE Standard |
ASSE 1003 |
| Connection Size |
2" x 2" |
| Connection Type |
FNPT x FNPT |
| Finish/Color |
Bronze |
| Height |
12" |
| Length |
10.9" |
| Material |
Low Lead Cast Bronze |
| Maximum Working Water Pressure |
300 psi |
| Maximum Working Water Temperature |
140 deg F |
| Mounting Type |
Vertical, Horizontal |
| Pressure Type |
Adjustable Pressure |
| Reduced Pressure Range |
25-75 psi (standard) |
| Size |
2" |
| Valve Body Material |
Low Lead Cast Bronze |
| Valve Style |
In-line (Backflow, PRVs, TMVs, RVs, etc.) |
| Weight |
21 lbs |
| Width |
6.5" |
