Honeywell Home V4044A1191/U 120 Vac 3/4 in Sweat Diverting QuickFit Zone Valve

The V4044A1191 is a two-position hydronic zone valve from Resideo, the brand that carries the Honeywell Home line of residential heating controls. It pairs a motorized actuator with a 3/4-inch sweat valve body to start and stop hot water flow to a single heating zone on a call from a thermostat or zone panel.

This is a diverting valve. Instead of simply opening and closing one path, it moves flow between two outlets, which is how a single circulator can serve a heating zone and an indirect water heater without a second pump.

The 3/4-inch sweat connections tie the valve into the supply piping, and the V4044A1191 handles supply water at operating pressures up to 300 psi.

This is a QuickFit model: the actuator head releases from the valve body without breaking the piping connection, so a failed motor is changed out without draining the system or unsoldering anything.

The V8043 and V4043 series have been the reference zone valves in North American hydronic heating for decades, and most contractors still order them by the original Honeywell part number. The actuator head is field-replaceable, so a burned-out motor does not mean cutting the body out of the line.

Replacement head and motor for this valve

• Honeywell Home 40003916-047/U Replacement Head for V4044A, 120 VAC, 60 Hz with 96 in leads

• Brand: Honeywell Home
• Manufacturer Part #: V4044A1191/U
• Valve action: Diverting
• Voltage: 120 Vac
• Connection size: 3/4 in
• Connection type: Sweat
• QuickFit actuator: Yes
• Max operating pressure: 300 psi
• Category: Zone Valves
