Description
Non-electric thermostatic operator for the V135 valve with a remote capillary, a sensing bulb that straps onto the pipe and an adjustable 50–122°F range.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: T100R1004
- Application: Radiator Accessory
- Scale Markings: 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12
- Body-Head Connection: 30 mm
- Radiator Connection Size: M30 x 1.5
- Closing Dimension: 11.5 mm
- Color: White
- Includes: External liquid-filled sensor with capillary tube, Handwheel with lid and socket, Connection nut standard, Spindle assembly, T1000R10 with contact sensor
- Set point Temperature (Max): 50 °C, 122 °F
- Set point Temperature (Min): 10 °C, 50 °F
- Sensor Length: 115 mm
- Sensor Location: Remote
- Sensor Type: Liquid-filled
- Control Temperature (Max): 122 °F, 50 °C
- Control Temperature (Min): 50 °F, 10 °C
- Hysteresis: 0.7 °F, 0.3 °C
- Remote Operation: Yes
- Compatible With: HVAC
- For Use With: V135 Mixing and Diverting Valves, V100 Straight Through Fluid Flow
- Warranty: 5 years
- Product Height: 77 mm
- Product Width: 50 mm
- UPC: 085267814218
- Country of Origin: DE
- Category: Thermostatic Radiator Controls & Valves
