Description
Industrial weekly/daily programmable timer for indoor and outdoor use, DPST, rated 30 A resistive, 10 A ballast, 1.5 hp at 120 V and 2 hp at 240 V.
Features
- Heavy-duty weather-proof casing (NEMA 3R) ideal for outdoor use
- Programming protected during power outage for 30 days
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: TI040/U
- Application: Industrial Indoor/Outdoor Timer
- Programming Options: Weekly/Daily Programming
- Motor Ratings: 1.5 HP @ 120 V AC, 2 HP @ 240 V AC
- Displayed Information: Mode, Time, Day, Program
- Warranty: 3 Years
- Electrical Connection: Terminals for #14 to #10 AWG wire, Multiswitch (3-way) compatible
- Electrical Ratings: Max Load - 30 A (resistive), 10 A (ballast), Inductive Load - 10 A @ 120/240 V AC, Resistive Load - 3600 W (30 A @ 120 V AC), Resistive Load - 7200 W (30 A @ 240 V AC)
- Operating Frequency: 50 Hz, 60 hZ
- Operating Voltage: 120 V, 240 V
- Color: Gray
- Product Height: 7.22 in, 182 mm
- Product Length: 6.22, 158 mm
- Product Width: 2.87 in, 73 mm
- Ambient Operating Temperature (Max): 122 °F, 50 °C
- Ambient Operating Temperature (Min): -4 °F, -20 ° C
- Shipping and Storage Temperature (Max): 122 °F, 50 °C
- Shipping and Storage Temperature (Min): -40 °F, -40 ° C
- UPC: 775264304033
- Country of Origin: CN
- Category: Programmable Switches
