Resideo MX127LF/U 1 in NPT Mixing Valve LF

Name: Resideo MX127LF/U 1 in NPT Mixing Valve LF
Brand: Resideo
SKU: HONE-MX127LF/U
Price: 799.36 USD
Availability: InStock

ResideoSKU: HONE-MX127LF/U

Price:

$799.36

Stock:

Re-stocking soon

Quantity:

Special order — typically ships in 3–4 weeks.
Contact us for an exact lead time.

Questions? Call (404) 678-9908 or chat with us.

Need 10+ or a project quote? Request a quote · Pros: open a trade account

Free shipping on orders $99+ · 30-day returns · Manufacturer warranty

Shipping details

Shipping weight: 4.1 lb
Box size: 11.95 × 9.2 × 5.7 in

⚠ WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Pipe Size	1 in.
Connection Type	NPT
Valve Type	Mixing Valves
Capacity (Cv)	4 Cv
Operating Temperature	113 F to 149 F
Application	Any application requiring accurate control of hot water temperature based on the mixing of hot and cold water, such as: domestic water for homes, apartment, hotels, schools, nursing homes, offices, public facilities, space heating, radiant floor heating,
Weight (lb)	3.6 lb
Approvals, ASSE	1017

The MX127LF is a lead-free thermostatic mixing valve from Resideo (Honeywell Home), 1 inch, NPT connection.

A mixing valve solves a problem that has no other answer: a water heater has to be kept hot enough to suppress bacterial growth in the tank, and that temperature is too hot to deliver to a tap. The valve blends stored hot water with cold on its way out, so the tank stays hot and the fixture does not.

Beyond safety, tempering buys capacity. A tank held hot and blended down delivers considerably more usable hot water than the same tank set to delivery temperature, because each gallon drawn is stretched with cold.

Lead free construction, as required for potable water in the United States.

Set the outlet temperature with a thermometer at the fixture, not by the dial alone, and re-check it after the system has settled. Inlet conditions move the mix, and a valve set on a cold line reads differently once the loop is up to temperature.

Brand: Resideo (Honeywell Home)
Manufacturer Part #: MX127LF/U
Type: Thermostatic mixing valve
Size: 1 in
Connection: NPT
Lead free: Yes
UPC: 085267182782
Shipping weight: 4.4 lb
Category: Mixing Valves

Full Specifications

Controlled Media	Potable Water, Non Potable Water
Re-Circulation	Yes
Approvals and Standards	ASSE 1017 Certified, CSA Listed, NSF/ANSI 61 Certified
Color	Metallic
Includes	(3) 1 in Gaskets, 1/2 in BSP recirculation adapter, Check Valves on Hot and Cold Inlets
Product Length	6.5 in, 165 mm
Product Weight	3.6 lb, 1.6 kg
Warranty	1 Year
Adjustment Means	Allen Key
Differential Pressure (Max)	7 psi, 48.3 kPa
Flex Connector Included	No
Flow Coefficient	4 Cv
Flow Rate (Min)	1 gpm, 3.78 lpm
Lead Free	Yes
Media Temperature (Max)	221 °F, 105 °C
Number of Check Valves	2
Operating Mixing Temperature (Min)	113 °F, 45 °C
Operating Mixing Temperature (Max)	149 °F, 65 °C
Operating Pressure (Max)	150 psi, 1034 kPa
Seal Material	Gun Metal
Valve Body Material	Teflon-coated, Bronze
Accessories	MX 050-RP/U
Connection Size	1 in
Connection Type	NPT
Nominal Diameter	DN25
Number of Connections	4
