Resideo R24AA3004/U Heat Sequencer, 1 Switch, On 30–90 sec, Off 1–30 sec

Heat sequencer with one switch, 30–90 sec on-timing and 1–30 sec off-timing.

Features

• Solid-state PTC Heaters
• Shock and vibration resistant

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: R24AA3004/U
• Application: Electric Heat
• Approvals and Standards: UL Approved File: 237660
• Contact Rating: 25 A at 120 or 240 V, 12.5 Amps at 480 V
• Electrical Connection Size: 1/4 in
• Electrical Connection Type: Solder or screw type quick connect
• Timing Delay: On-timing -- 30 to 90 sec, Off-timing-- 1 to 30 sec
• Ambient Operating Temperature (Min): -40 °F, -40 °C
• Ambient Operating Temperature (Max): 165 °F, 73.8 C
• UPC: 085267277907
• Country of Origin: CN
• Category: Relays
