Resideo R24DB4005/U Heat Sequencer, 4 Switches, On 1–110 sec, Off 1–110 sec
Resideo

Resideo R24DB4005/U Heat Sequencer, 4 Switches, On 1–110 sec, Off 1–110 sec

Item #
HONE-R24DB4005/U
Mfr. part #
R24DB4005/U
UPC
085267277952
$56.71
Each
Backorder – ships from manufacturer
Estimated delivery: –

Special order: typically ships in 3–4 weeks. Contact us for an exact lead time.

5% off at checkout with code SAVE5

Buying for a business? Tax-exempt purchasing and Net 30 terms available. Open a trade account

  • Free shipping on orders $99+
  • 30-day returns on unused items. Details
  • Secure checkout

Shipping details

  • Shipping weight: 0.29 lb
  • Box size: 3.45 × 2.75 × 2.2 in
Need help with this part?
(404) 678-9908 Chat with a product specialist Request a quote
BrandResideo
Manufacturer part #R24DB4005/U
UPC085267277952

Heat sequencer with four switches, 1–110 sec on-timing and 1–110 sec off-timing (all switches).

Features

  • Solid-state PTC Heaters
  • Shock and vibration resistant

Specifications

  • Brand: Resideo (Honeywell Home)
  • Manufacturer Part #: R24DB4005/U
  • Application: Electric Heat
  • Approvals and Standards: UL Approved File: 237660
  • Contact Rating: 25 A at 120 or 240 V, 12.5 Amps at 480 V
  • Electrical Connection Size: 1/4 in
  • Electrical Connection Type: Solder or screw type quick connect
  • Timing Delay: On-timing -- 1 to 110 sec (first, second, third and fourth switches), Off-timing-- 1 to 110 sec (first, second, third, and fourth switches)
  • Ambient Operating Temperature (Min): -40 °F, -40 °C
  • Ambient Operating Temperature (Max): 165 °F, 73.8 C
  • UPC: 085267277952
  • Country of Origin: CN
  • Category: Relays
