Description
VC valve and actuator assembly for Trane, 0.5 in sweat, 24 V 50/60 Hz, 120 sec timing, 8 in lead wire.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: VC6930MA6132/U
- Controlled Media: 50% (maximum) Glycol Mixture
- Approvals and Standards: CSA Certified
- Color: Bronze
- Includes: Trane label
- Warranty: 1 Year
- Ambient Operating Temperature (Min): 32 °F, 0 °C
- Ambient Operating Temperature (Max): 150 °F, 65 °C
- Connection Type: Sweat
- Differential pressure for close-off (Max): 60 psi, 400 kPa
- Flow Coefficient: 3.8 Cv; 3.3 Kvs
- Media Temperature (Min): 34 °F, 1 °C
- Media Temperature (Max): 203 °F, 95 °C
- Operating Pressure (Max): 300 psi, 2068 kPa (20 Bar)
- Seal Material: EPDM Rubber
- Shipping and Storage Temperature (Min): -40 °F, -40 °C
- Valve Body Material: Bronze
- Valve Body Pattern: Three-way
- Valve Flow Characteristic: Linear
- Valve Seat Material: EPDM
- Valve Stem Material: Stainless Steel
- Valve Stem Travel: 0.4 in, 10 mm
- UPC: 085267833929
- Country of Origin: HU
- Category: 3-Way Zone Valve
