Resideo TAXV-144/U TAXV Thermal Expansion Tank, 70 gal, Vertical, 1 in Male NPT, ASME
Resideo

Resideo TAXV-144/U TAXV Thermal Expansion Tank, 70 gal, Vertical, 1 in Male NPT, ASME

Item #
HONE-TAXV-144/U
Mfr. part #
TAXV-144/U
UPC
085267829298
$5,257.17
Each
Backorder – ships from manufacturer
Estimated delivery: –

Special order: typically ships in 3–4 weeks. Contact us for an exact lead time.

Buying for a business? Tax-exempt purchasing and Net 30 terms available. Open a trade account

Pricing a job? Get a written quote →Open a trade account

  • Ships by freight truck (LTL), contiguous U.S. only
  • 30-day returns on unused items. Details
  • Secure checkout

Shipping details

  • Shipping weight: 299.0 lb
Need help with this part?
(404) 678-9908 Chat with a product specialist Request a quote
BrandResideo
Manufacturer part #TAXV-144/U
UPC085267829298

TAXV series 70 gallon vertical thermal expansion tank with 1 in male NPT connection, ASME construction, for closed heating systems only.

Specifications

  • Brand: Resideo (Honeywell Home)
  • Manufacturer Part #: TAXV-144/U
  • Application: Hydronic Volume Expansion
  • Approvals and Standards: ASME Construction
  • Compatible With: Closed Heating Systems
  • Operating Temperature (Max): 240 °F, 115 °C
  • Tank Safe Operating Pressure (Max): 125 psi, 862 kPa
  • Connection Size: 1 in
  • Connection Type: NPT
  • Connector Type: Male
  • Warranty: 1 Year
  • Color: Red
  • Body Material: Steel
  • Diaphragm Material: Butyl/EPDM Compound
  • Maximum Acceptance Volume: 34 gal, 128.9 L
  • Product Height: 49.13 in, 1247.8 mm
  • Product Weight: 256 lb, 116.4 kg
  • Pre-Charge Pressure: 12 psi, 83 kPa
  • UPC: 085267829298
  • Country of Origin: US
  • Category: System Fill Tanks & Autofills
