Resideo TAXV-060/U TAXV Thermal Expansion Tank, 33.6 gal, Vertical, 1/2 in Male NPT, ASME
Resideo

Resideo TAXV-060/U TAXV Thermal Expansion Tank, 33.6 gal, Vertical, 1/2 in Male NPT, ASME

Item #
HONE-TAXV-060/U
Mfr. part #
TAXV-060/U
UPC
085267829250
$2,170.09
Each
Backorder – ships from manufacturer
Estimated delivery: –

Special order: typically ships in 3–4 weeks. Contact us for an exact lead time.

Ships UPS Ground for a flat $189 (continental US).
Flat rate by order weight: $119 under 70 lb · $149 for 70–100 lb · $189 for 100–150 lb.

Buying for a business? Tax-exempt purchasing and Net 30 terms available. Open a trade account

Pricing a job? Get a written quote →Open a trade account

  • Ships from Seattle, WA
  • 30-day returns on unused items. Details
  • Secure checkout

Shipping details

  • Shipping weight: 145.0 lb
Need help with this part?
(404) 678-9908 Chat with a product specialist Request a quote
BrandResideo
Manufacturer part #TAXV-060/U
UPC085267829250

TAXV-060 has been discontinued by the manufacturer (2022-05). Direct replacement: 117-728 - AX-60V Extrol Expansion Tank (33.6 Gallon Volume) - Vertical Model (Amtrol) (not listed on our site yet - contact us).

TAXV series 33.6 gallon vertical thermal expansion tank with 1/2 in male NPT connection, ASME construction, for closed heating systems only.

Specifications

  • Brand: Resideo (Honeywell Home)
  • Manufacturer Part #: TAXV-060/U
  • Application: Hydronic Volume Expansion
  • Approvals and Standards: ASME Construction
  • Compatible With: Closed Heating Systems
  • Operating Temperature (Max): 240 °F, 115 °C
  • Tank Safe Operating Pressure (Max): 125 psi, 862 kPa
  • Connection Size: 1/2 in
  • Connection Type: NPT
  • Connector Type: Male
  • Warranty: 1 Year
  • Color: Red
  • Body Material: Steel
  • Diaphragm Material: Butyl/EPDM Compound
  • Maximum Acceptance Volume: 11.3 gal, 42.8 L
  • Product Height: 45.13 in, 1146 mm
  • Product Weight: 145 lb, 65.9 kg
  • Pre-Charge Pressure: 12 psi, 83 kPa
  • UPC: 085267829250
  • Country of Origin: US
  • Category: System Fill Tanks & Autofills

Questions about fit or compatibility? Ask our team. We usually reply within one business day.
