Resideo TAXV-020/U TAXV Thermal Expansion Tank, 10.9 gal, Vertical, 1/2 in Male NPT, ASME
Resideo

Resideo TAXV-020/U TAXV Thermal Expansion Tank, 10.9 gal, Vertical, 1/2 in Male NPT, ASME

Item #
HONE-TAXV-020/U
Mfr. part #
TAXV-020/U
UPC
085267829236
$2,113.56
Each
Backorder – ships from manufacturer
Estimated delivery: –

Special order: typically ships in 3–4 weeks. Contact us for an exact lead time.

Buying for a business? Tax-exempt purchasing and Net 30 terms available. Open a trade account

Pricing a job? Get a written quote →Open a trade account

  • Free shipping on orders $99+
  • 30-day returns on unused items. Details
  • Secure checkout

Shipping details

  • Shipping weight: 61.0 lb
Need help with this part?
(404) 678-9908 Chat with a product specialist Request a quote
BrandResideo
Manufacturer part #TAXV-020/U
UPC085267829236

TAXV-020 has been discontinued by the manufacturer (2020-06). No direct replacement has been published by the manufacturer. Contact us for help choosing an alternative.

TAXV series 10.9 gallon vertical thermal expansion tank with 1/2 in male NPT connection, ASME construction, for closed heating systems only.

Specifications

  • Brand: Resideo (Honeywell Home)
  • Manufacturer Part #: TAXV-020/U
  • Application: Hydronic Volume Expansion
  • Approvals and Standards: ASME Construction
  • Compatible With: Closed Heating Systems
  • Operating Temperature (Max): 240 °F, 115 °C
  • Tank Safe Operating Pressure (Max): 125 psi, 862 kPa
  • Connection Size: 1/2 in
  • Connection Type: NPT
  • Connector Type: Male
  • Warranty: 1 Year
  • Color: Red
  • Body Material: Steel
  • Diaphragm Material: Butyl/EPDM Compound
  • Maximum Acceptance Volume: 11.3 gal, 42.8 L
  • Product Height: 26 in, 660 mm
  • Product Weight: 61 lb, 27.7 kg
  • Pre-Charge Pressure: 12 psi, 83 kPa
  • UPC: 085267829236
  • Country of Origin: US
  • Category: System Fill Tanks & Autofills
