Description
TAXV series 7.8 gallon vertical thermal expansion tank with 1/2 in male NPT connection, ASME construction, for closed heating systems only.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: TAXV-015/U
- Application: Hydronic Volume Expansion
- Approvals and Standards: ASME Construction
- Compatible With: Closed Heating Systems
- Operating Temperature (Max): 240 °F, 115 °C
- Tank Safe Operating Pressure (Max): 125 psi, 862 kPa
- Connection Size: 1/2 in
- Connection Type: NPT
- Connector Type: Male
- Warranty: 1 Year
- Color: Red
- Body Material: Steel
- Diaphragm Material: Butyl/EPDM Compound
- Maximum Acceptance Volume: 3.2 gal, 12.1 L
- Product Height: 19.25 in, 489 mm
- Product Weight: 48 lb, 21.8 kg
- Pre-Charge Pressure: 12 psi, 83 kPa
- UPC: 085267829229
- Country of Origin: US
- Category: System Fill Tanks & Autofills
