Resideo TH115-AF-120S/U 7-Day Programmable Thermostat with Floor Sensor, 120 V, 16.7 A, Single Pole

7-day programmable thermostat with floor temperature sensor for ambient or floor control, rated 16.7 A at 120 V, single pole, with a backlit screen.

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: TH115-AF-120S/U
• Application: Baseboard heater, Radiant ceiling, Convector or Fan-forced Heater, Electric Heating, Radiant Floor
• Thermostat Type: Programmable, Low Voltage
• Smart Home Integration: No
• Display Type: LCD Screen
• Display Size: 10 sq in
• Modes of Operation: Heat, Off
• Program Type: 7-Day Programmable
• Power Supply: Hardwired
• Frequency: 50 Hz, 60 Hz
• Warranty: 3 Years
• Includes: 15-feet / 4.6-m floor sensor
• Z-Wave Specifications: Not Applicable
• RedLINK: No
• Color: White
• Sensor Type: Thermistor
• Ambient Operating Temperature (Max): 120 °F, 49 °C
• Ambient Operating Temperature (Min): 32 °F, 0 °C
• Differential Temperature: ± 1 °F, ± 0.5 °C
• Backlight Options: Backlight Button
• Clock Type: Year Clock
• Electrical Connection Type: Screw terminals
• Mounting Type: Vertical Mount
• Number of Fan Speeds: 2
• Set point Temperature (Max): 86 °F, 30 °C
• Set point Temperature (Min): 40 °F, 5 °C
• Switch Action: SPST
• Switch Type: Epoxy-soundproofed relay
• Product Height: 4.9 in, 2.8 mm
• Product Length: 2.8 in, 70 mm
• Product Width: 0.9 in, 23 mm
• Product Depth: 1.25 in
• UPC: 775264921223
• Country of Origin: CN
• Category: Line Voltage Thermostats
