Resideo TH140-28-01-B/U 7-Day Programmable Thermostat, 1 Heat, SPDT, 24/120/240 V

Item #: HONE-TH140-28-01-B/U
Mfr. part #: TH140-28-01-B/U
UPC: 775264140235

$114.73

Free shipping on orders $99+
30-day returns on unused items. Details
Secure checkout

Need help with this part?

(404) 678-9908 Chat with a product specialist Request a quote

Brand	Resideo
Manufacturer part #	TH140-28-01-B/U
UPC	775264140235

Battery-powered 7-day programmable thermostat for 1 heat, SPDT, 5 A resistive/2 A inductive at 24/120/240 V, with circulating pump protection.

Specifications

Brand: Resideo (Honeywell Home)
Manufacturer Part #: TH140-28-01-B/U
Application: Electric Baseboards, Convectors and Fan-forced Heaters (Resistive Rated Loads), Pump protection for hot water heating
Thermostat Type: Programmable
Approvals and Standards: CSA Listed: File No. LR1322, UL Listed; File No. E4436, Guide No. XAPX
Stages: 1 Heat
Smart Home Integration: No
Display Type: Digital, LCD Screen, Backlit Display
Display Size: 10 sq in
Touchscreen: No
IAQ Capability: Not Applicable
Modes of Operation: Heat
Program Type: 7-Day Programmable
Power Supply: Battery Powered
Battery Type: Alkaline
Frequency: 50 Hz, 60 Hz
Battery Life: 1
Battery Size: AA
Warranty: 3 Years
Includes: Range stops, Locking cover, Extra knob decal for recalibration
For Use With: Aube RC840 or RC840T Series Electromechanical Relays, Aube CT240 Telephone Controller
Z-Wave Specifications: Not Applicable
RedLINK: No
Color: White
Sensor Type: Thermistor
Ambient Operating Temperature (Max): 122 °F, 50 °C
Ambient Operating Temperature (Min): 32 °F, 0 °C
Differential Temperature: ± 1 °F, ± 0.5 °C
Clock Type: Week Clock
Mounting Type: Vertical Mount
Number of Fan Speeds: 2
Set point Temperature (Max): 85 °F, 30 °C
Set point Temperature (Min): 40 °F, 30 °C
Switch Action: SPDT
Switch Type: Relay
Product Height: 4.9 in, 127 mm
Product Length: 3.8 in, 97 mm
Product Width: 1 in, 26 mm
Product Depth: 1.94 in, 33 mm
UPC: 775264140235
Country of Origin: CN
Category: Line Voltage Thermostats
