Description
Zone valve with 3/4 in sweat connection, 8 Cv, 8 psi close-off, and 300 psi static rating.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: V8043F5093/U
- Valve Ball Material: Buna-N (NBR) Rubber
- Approvals and Standards: CSA C/US: File 1322
- Color: Brass
- Includes: End switch enclosure, Manual Opener
- Product Height: 4.38 in, 111 mm
- Product Length: 2.38 in, 60 mm
- Product Width: 3.69 in, 89 mm
- Warranty: 1 Year
- Ambient Operating Temperature (Max): 125 °F, 52 °C
- Connection Type: Sweat
- Differential pressure for close-off (Max): 8 psi, 55 kPa
- Flow Coefficient: 8 Cv; 6.9 Kvs
- Media Temperature (Min): 50 °F, 10 °C
- Media Temperature (Max): 200 °F, 93 °C
- Static Pressure Rating: 300 psi, 2068 kPa
- Valve Body Material: Brass
- Valve Body Pattern: Two-way, Straight Through
- Valve Plug Material: Buna-N (NBR) Rubber
- Valve Seat Material: Brass
- Valve Start Position: Closed
- Valve Stem Material: Stainless Steel
- UPC: 085267833585
- Country of Origin: HU
- Category: 2-Way Zone Valve
