Honeywell Home VC6934ZZ31/U VC Floating Valve Actuator, 24 VAC 50/60 Hz, 3-Wire Cable

Floating VC valve actuator, 24 V 50/60 Hz, with 3-wire cable.

Features

• Use with two-way or three-way valves
• Double insulated actuator
• Five foot plenum-rated cable
• Quick and easy replacement of moving parts
• Actuator head installation does not require draining the system
• Selectable/switchable electronic fail safe normally open or normally closed
• Available with valve bodies with 1000-series 2-way and 6000-series 3-way cartridges for new construction
• All VC Series actuator-valve combinations provide 60 psi close-off

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: VC6934ZZ31/U
• Application: Proportional Control
• Approvals and Standards: Listed 94-5V, CSA Certified: LR1322-367, 89/336/ECC, 73/23/EEC
• For Use With: SPDT/Floating Low Voltage thermostats with molex connectors, Use with 2-way or 3-way VC Valve body
• Compatible With: Use in cold, warm, and hot water applications
• Warranty: 1 Year
• Includes: 3/8 in Flexible conduit adapter, Kele label
• Media Temperature (Min): 34 °F, 1 °C
• Media Temperature (Max): 203 °F, 95 °C
• Ambient Operating Temperature (Min): 32 °F, 0 °C
• Ambient Operating Temperature (Max): 150 °F, 65 °C
• Shipping and Storage Temperature (Min): -40 °F, -40 °C
• Operating Relative Humidity (Min): 5% Non-condensing
• Operating Relative Humidity (Max): 95% Non-condensing
• Fail-Safe Operation Type: Stays in place
• Voltage: 24 Vac
• Power Consumption: 6 VA
• Differential pressure for close-off (Max): 60 psi, 400 kPa
• Actuator Connection: Valve
• Stroke (Max): 0.4 in, 10 mm
• Color: Bronze
• Product Height: 2.7 in, 68 mm
• Product Length: 3.7 in, 94 mm
• Product Weight: 0.84 lb, 0.38 kg
• UPC: 085267831802
• Country of Origin: HU
• Category: Zone Valve Replacement Heads
