Honeywell Home VC8715ZZ11/U VC 2-Position On/Off Actuator, 24 VAC 60 Hz, Aux Switch, 1 m Cable

Two-position (on/off) 24 V 60 Hz 2-wire plus common actuator with 1 m cable and auxiliary switch, for SPST controllers; capacitor on circuit board, works with T8400C1024.

Features

• Use with two-way or three-way valves
• Double insulated actuator
• Five foot plenum-rated cable
• Quick and easy replacement of moving parts
• Actuator head installation does not require draining the system
• Selectable/switchable electronic fail safe normally open or normally closed
• Available with valve bodies with 1000-series 2-way and 6000-series 3-way cartridges for new construction
• Self-Alignment Shaft Adapter

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: VC8715ZZ11/U
• Application: HVAC
• Approvals and Standards: UL Recognized, File# MH11826, CSA Certified: LR1322-367, CE Approval: 89/336/ECC, CE Approval: 73/23/EEC
• For Use With: VC Series Valves, 1000 Series 2-way, 6000 Series 3-way
• Compatible With: Use in cold, warm, and hot water applications
• Control Signal: SPST, Two position
• Warranty: 1 Year
• Media Temperature (Max): 203 °F, 95 °C
• Mounting Type: Direct Coupled
• Ambient Operating Temperature (Min): 32 °F, 0 °C
• Ambient Operating Temperature (Max): 150 °F, 65 °C
• Shipping and Storage Temperature (Min): -40 °F, -40 °C
• Shipping and Storage Temperature (Max): 150 °F, 65 °C
• Operating Relative Humidity (Min): 5% Non-condensing
• Operating Relative Humidity (Max): 95% Non-condensing
• Protection Class: Double Insulated, IP40
• Fail-Safe Operation Type: Stays in place
• Drive Time: 6 sec
• Supply Voltage: 24 V AC
• Power Supply Frequency: 60 Hz
• Power Consumption: 6 VA, 3W standby for thermostat anticipator
• Differential pressure for close-off (Max): 60 psid, 400 kPa
• Number of Internal Auxiliary Switches: 1
• Actuator Connection: Valve
• Connection Length: 39 in, 1 m
• Connection Type: Cable
• Stroke (Max): 0.4 in, 10 mm
• Product Height: 2.8 in, 70 mm
• Product Weight: 0.84 lb, 0.38 kg
• Product Width: 3.7 in, 94 mm
• Product Depth: 2.7 in, 68 mm
• Housing Material: Plastic
• UPC: 085267820721
• Country of Origin: HU
• Category: Zone Valve Replacement Heads
