Resideo VR9205R2363T/U Direct Ignition Gas Valve for Pneumatic Furnace Modulation

Direct ignition gas valve for pneumatic furnace modulation.

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: VR9205R2363T/U
• Application: Modulating Valve
• Ignition Type: Direct Burner Ignition
• Type of Fuel: Natural Gas
• Capacity (Max): 200,000 BTU/h
• Operating Voltage: 24 V AC
• Inlet Connection Size: 1/2 in
• Outlet Connection Size: 1/2 in
• Regulation Type: Modulating
• Pressure Rating: 1/2 psi, 3.5 kPa
• Operating Pressure (Max): 1/2 psi
• For Use With: Gas Air Valve
• Valve Body Pattern: Straight Through
• Ambient Operating Temperature (Max): 175 °F, 79 °C
• Ambient Operating Temperature (Min): -40 °F, -40 °C
• Approvals and Standards: CSA Certified: LR112491
• Color: Gray, Black
• Mounting Type: 0° to 90° in any direction from the upright position of the gas control knob, including vertically
• Operating Frequency: 50 Hz, 60 Hz
• Product Height: 4.04 in, 103 mm
• Product Width: 5.04 in, 128 mm
• UPC: 085267702447
• Country of Origin: MX
• Category: Gas Valves
