Resideo AT150B1146/U Control Transformer, 50 VA, 120/208/240 V, 9 in Leadwires
Resideo

Resideo AT150B1146/U Control Transformer, 50 VA, 120/208/240 V, 9 in Leadwires

Item #
HONE-AT150B1146/U
Mfr. part #
AT150B1146/U
UPC
085267035439
$37.34
Each
Backorder – ships from manufacturer
Estimated delivery: –

Special order: typically ships in 3–4 weeks. Contact us for an exact lead time.

5% off at checkout with code SAVE5

Buying for a business? Tax-exempt purchasing and Net 30 terms available. Open a trade account

  • Ships from Seattle, WA
  • 30-day returns on unused items. Details
  • Secure checkout

Shipping details

  • Shipping weight: 2.1 lb
  • Box size: 4 × 2 × 2 in
Need help with this part?
(404) 678-9908 Chat with a product specialist Request a quote
BrandResideo
Manufacturer part #AT150B1146/U
UPC085267035439

AT150B1146 has been discontinued by the manufacturer (2024-01). Direct replacement: AT150B1237 - Foot Mounted 120/208/240 Vac Transformer w/ 9 in. Lead Wires w/ Plastic End Caps.

50 VA control transformer rated 120/208/240 V, 60 Hz, with 9 in primary and secondary leadwires.

Specifications

  • Brand: Resideo (Honeywell Home)
  • Manufacturer Part #: AT150B1146/U
  • NEMA Rating: No
  • Primary Connection Size: 9 in, 229 mm
  • Primary Connection Type: Leadwires: Black - COM; White - 120 V; Red - 208 V; Orange - 240 V
  • Primary Input Voltage: 120/208/240 V ac
  • Secondary Connection Size: 9 in, 229 mm
  • Secondary Connection Type: Leadwires
  • Secondary Open Circuit Voltage: 27.5 V.O.C.
  • VA Rating: 50 VA
  • Frequency: 60 Hz
  • Approvals and Standards: UL Component Recognized: B, D, E models. File# E14881, CSA Certified: A & B models, NEC Class 2
  • Ambient Operating Temperature (Max): 105 °F, 41 °C
  • Ambient Operating Temperature (Min): -20 °F, -29 °C
  • Product Height: 1.69 in, 43 mm
  • Product Width: 3.5 in, 89 mm
  • UPC: 085267035439
  • Country of Origin: CN
  • Category: Transformers

Questions about fit or compatibility? Ask our team. We usually reply within one business day.

$37.34
Backorder
