Description
40 VA transformer with a 120 V primary and 24 V output, mounted on a box plate.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: AT72D1188/U
- Application: 40 VA transformers power 24 V systems including thermostats, gas valves and relays.
- NEMA Rating: Yes
- Primary Connection Size: 9 in, 229 mm
- Primary Connection Type: Leadwires: Black and White
- Primary Input Voltage: 120 V ac
- Secondary Connection Size: 9 in, 229 mm
- Secondary Connection Type: Leadwires
- Secondary Open Circuit Voltage: 26.5 V.O.C.
- VA Rating: 40 VA
- Frequency: 50 Hz; 60 Hz
- Approvals and Standards: UL Component Recognized, CSA Certified, NEC Class 2
- Ambient Operating Temperature (Max): 105 °F, 41 °C
- Ambient Operating Temperature (Min): -20 °F, -29 °C
- Product Height: 3.22 in, 81.8 mm
- Product Width: 2.22 in, 56.4 mm
- UPC: 085267035958
- Country of Origin: CN
- Category: Transformers
