Resideo AT87A1155/U Transformer, 480 V, 12 in Leadwires, Foot Mount

480 V transformer with 12 in primary and secondary leadwires and foot mounting.

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: AT87A1155/U
• Application: 48 VA powers 24V air conditioning circuits and other applications that do not exceed the listed ratings.
• NEMA Rating: Yes
• Primary Connection Size: 12 in, 305 mm
• Primary Connection Type: Leadwires: Black and Black/Red
• Primary Input Voltage: 480 V ac
• Secondary Connection Size: 12 in, 305 mm
• Secondary Connection Type: Leadwires
• Secondary Open Circuit Voltage: 26.5 V.O.C.
• VA Rating: 50 VA
• Frequency: 50 Hz; 60 Hz
• Approvals and Standards: UL Component Recognized, CSA Certified, NEC Class 2
• Includes: Energy limiting overload protection
• Ambient Operating Temperature (Max): 105 °F, 41 °C
• Ambient Operating Temperature (Min): -20 °F, -29 °C
• Product Width: 2.22 in, 56.4 mm
• UPC: 085267036191
• Country of Origin: CN
• Category: Transformers
