Resideo SV9520H8513/U Direct Ignition SmartValve, Fast-Slow Opening, 1/2 in x 1/2 in, 3.5 in WC

Item #: HONE-SV9520H8513/U
Mfr. part #: SV9520H8513/U
UPC: 085267297721

$447.84

Free shipping on orders $99+
30-day returns on unused items. Details
Secure checkout

Shipping details

Shipping weight: 2.1 lb
Box size: 6.55 × 5.45 × 3.6 in

Installation by a licensed gas technician is required. Confirm the part against your appliance's parts list.

Need help with this part?

(404) 678-9908 Chat with a product specialist Request a quote

Brand	Resideo
Manufacturer part #	SV9520H8513/U
UPC	085267297721

Direct ignition SmartValve gas valve with fast-slow opening, 1/2 in x 1/2 in, 3.5 in WC setting, 15-second prepurge, and 7-second ignition trial; includes conversion kit.

Specifications

Brand: Resideo (Honeywell Home)
Manufacturer Part #: SV9520H8513/U
Application: Single-Stage Fast-Slow Opening Valve with Direct Hot Surface Pilot Ignition
Ignition Type: Direct Hot Surface Ignition
Type of Fuel: Natural Gas
Regulation Type: Fast-Slow Opening
Capacity (Max): 200 ft³/hr, 5.7 m³/hr
Capacity (Min): 20 ft³/hr, 0.6 m³/hr
Operating Voltage: 24 V AC
Inlet Connection Size: 1/2 in
Inlet Connection Type: NPT
Outlet Connection Size: 1/2 in
Outlet Connection Type: NPT
Pressure Regulator Set point: 3.5 in WC, 0.87 kPa
Pressure Tap Connection Size: 1/8 in
Pressure Tap Connection Type: NPT
Typical Ignition Hardware: Norton 601
Ignition Trials To Lockout: 4 Trials
Pre-Purge: 15 seconds
Universal: Yes
For Use With: ST9160 Electronic Fan Timer
Compatible With: Intermittent Pilot Burners, Gas-fired Systems
Valve Body Pattern: Straight Through
Ambient Operating Temperature (Max): 175 °F, 79 °C
Ambient Operating Temperature (Min): 0 °F, -18 °C
Mounting Type: 0° to 90° in any direction from the upright position of the gas control knob, including vertically
Operating Frequency: 50 Hz, 60 Hz
Pilot Gas Outlet: No
Product Height: 4.9 in
Product Length: 4.1 in
Product Width: 3.2 in
UPC: 085267297721
Country of Origin: MX
Category: Gas Valves
