Description
Direct ignition SmartValve with standard opening, 1/2 in x 1/2 in connections, 3.5 in WC setting, 15 second prepurge and 7 second ignition trial, supplied with a conversion kit.
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: SV9520M2536/U
- Application: Single-Stage Standard Opening Valve with Direct Hot Surface Pilot Ignition
- Ignition Type: Direct Hot Surface Ignition
- Type of Fuel: LP with included conversion kit, Natural Gas
- Regulation Type: Standard Opening
- Capacity (Max): 200 ft³/hr, 5.7 m³/hr
- Capacity (Min): 20 ft³/hr, 0.6 m³/hr
- Operating Voltage: 24 V AC
- Inlet Connection Size: 1/2 in
- Inlet Connection Type: NPT
- Outlet Connection Size: 1/2 in
- Outlet Connection Type: NPT
- Pressure Regulator Set point: 3.5 in WC, 0.87 kPa
- Pressure Tap Connection Size: 1/8 in
- Pressure Tap Connection Type: NPT
- Ignition Trials To Lockout: 4 Trials
- Pre-Purge: 15 seconds
- Includes: LP Conversion Kit
- Compatible With: Intermittent Pilot Burners, Gas-fired Systems
- Valve Body Pattern: Straight Through
- Ambient Operating Temperature (Max): 175 °F, 79 °C
- Ambient Operating Temperature (Min): -40 °F, -40 °C
- Approvals and Standards: CAS International: 158158-10592145
- Mounting Type: 0° to 90° in any direction from the upright position of the gas control knob, including vertically
- Operating Frequency: 50 Hz, 60 Hz
- Product Height: 4.9 in, 124 mm
- Product Length: 4.1 in, 104 mm
- Product Width: 3.2 in, 81 mm
- UPC: 085267297707
- Country of Origin: MX
- Category: Gas Valves
