Resideo TH114-A-024T-15S/U Low Voltage Non-Programmable Thermostat, 24 V, 0.5 A, 15-Second Cycles

TH114 thermostat rated 0.5 A at 24 V with R, C, W terminals and 15-second cycles.

Specifications

• Brand: Resideo (Honeywell Home)
• Manufacturer Part #: TH114-A-024T-15S/U
• Application: Electric Heating; Baseboard heater; Radiant ceiling; Convector
• Thermostat Type: Low Voltage, Non programmable
• Smart Home Integration: No
• Display Type: LCD Screen
• Display Size: 6.89 sq in
• Displayed Information: Indoor Temperature, Heating Intensity Indicator
• Modes of Operation: Heat
• Program Type: Manual / Not Programmed
• Energy Star Certified: No
• Power Supply: Hardwired
• Warranty: 3 Years
• For Use With: Aube RC850/RC850T Series Solid State Relays
• Z-Wave Specifications: Not Applicable
• RedLINK: No
• Color: White
• Sensor Type: Thermistor
• Ambient Operating Temperature (Max): 122 °F, 50 °C
• Ambient Operating Temperature (Min): 32 °F, 0 °C
• Differential Temperature: ± 1 °F, ± 0.5 °C
• Backlight Options: Backlight Button
• Temperature Accuracy: 0.9, 0.5
• Electrical Connection Type: UWP Mounting System
• Mounting Type: Vertical Mount
• Number of Fan Speeds: 2
• Set point Temperature (Max): 86 °F, 30 °C
• Set point Temperature (Min): 40 °F, 5 °C
• Switch Type: External solid state relay
• Product Height: 4.9 in, 2.8 mm
• Product Length: 2.8 in, 70 mm
• Product Width: 0.9 in, 23 mm
• UPC: 775264924927
• Country of Origin: CN
• Category: Non-Programmable Thermostats
