Sioux Chief

Sioux Chief products in the catalog span drainage and rough-in plumbing. Items include PVC, ABS and chrome P-traps with trap adapters, center and end outlet wastes, disposer kits, trap primer and branch tailpieces, plus cleanouts, adjustable floor drains, shower drains, F1807 crimp and F1960 expansion PEX fittings, and tube hangers.

For tubular drain parts, match the tube diameter (1-1/4" or 1-1/2"), material and joint type, slip joint or solvent weld. For drains and cleanouts, confirm the pipe size and material the body connects to; for PEX fittings, the connection standard your tool uses.

See also: P-Traps, Floor Drains, F1807 Crimp Fittings.

Popular in this collection: Sioux Chief 687-2XD PEX Single Valve Service Box, Sioux Chief 598-023 Expansion Tank Bracket, Sioux Chief 869-2A 2" ABS Backwater Valve.

Frequently asked questions

What does a backwater valve do?

A backwater valve lets wastewater flow out of the building but closes if the sewer backs up, so sewage cannot come back in through floor drains and low fixtures. Match the valve to the pipe size and material, such as 2" ABS.

Why support an expansion tank with a bracket?

A thermal expansion tank full of water is heavy, and hanging it from the water heater piping puts that weight on the fittings. A bracket such as the Sioux Chief 598-023 carries the tank so the piping does not have to.

F1807 crimp or F1960 expansion PEX fittings?

They are different systems with different tools. F1807 fittings are crimped with a copper or stainless ring; F1960 fittings need expansion PEX tubing and an expansion tool. Match the fitting to the system already installed. See F1807 crimp fittings.
