Description
Two stage direct ignition gas valve with standard opening, 1/2 in x 1/2 in connections and 1.7/3.5 in WC settings.
Features
- ON-OFF Lighting Sequence
Specifications
- Brand: Resideo (Honeywell Home)
- Manufacturer Part #: VR8205Q2746T/U
- Application: Two-Stage Standard Opening Valve for Direct Burner Ignition
- Ignition Type: Direct Burner Ignition
- Type of Fuel: Natural Gas
- Capacity (Min): 20,000 BTU/h
- Operating Voltage: 24 V AC
- Inlet Connection Size: 1/2 in
- Outlet Connection Size: 1/2 in
- Regulation Type: Standard Two Stage
- For Use With: S89C, S89E, S89F, S87 Series 5 and later
- Valve Body Pattern: Straight Through
- Ambient Operating Temperature (Max): 175 °F, 79 °C
- Ambient Operating Temperature (Min): -40 °F, -40 °C
- Approvals and Standards: UL Component Recognized MH5323, CSA International: 112395, Australian Gas Association design certificate: 4214, Approved for Delta C Applications
- Color: Black, Gray
- Mounting Type: 0° to 90° in any direction from the upright position of the gas control knob, including vertically
- Operating Frequency: 60 Hz
- Product Height: 4.63 in, 117 mm
- Product Weight: 0.31 lb
- Product Width: 4.13 in, 104 mm
- UPC: 085267633895
- Country of Origin: MX
- Category: Gas Valves
